Magnetic Printing Belt Puller Machine PM-500

The PM-500 Laboratory Printing Machine is suitable for quality control, color recipe applications, and research and development of new printing products. It eliminates inconsistencies caused by manual operations. By establishing a printing laboratory automation system, it ensures high repeatability between tests.
The operator can easily adjust all parameters using touch-screen controls with a user-friendly interface. The sliding bar's printing speed, operating range, and pressure can be adjusted via an electromagnet. Additionally, the printing table is equipped with special clamps to secure the template in the correct position and wheels to make it movable.
Features:

• Controls: Touch Screen
• Maximum Printing Dimensions (Width/Length): 500mm x 500mm
• Bar Diameter: 8/10/16mm (Each can be provided)
• Bar Length: 500mm
• Working Range: 0mm-500mm (Adjustable)
• Working Speed: 0 – 10 m/min (Adjustable)
• Power: 220V x Single-phase x 0.4KW
• Dimensions: 127cm (W) x 88cm (D) x 103cm (H)
• Weight: 160kg
